| Part No |
90NR0IN2-M00060 |
| Model Name |
G834JZR-R6005W |
| TTV |
2023-11-27 |
| End of Production |
2024-12-31 |
| EAN Code |
4711387379646 |
| UPC Code |
197105379640 |
| WEEE |
3.603 |
| BASE UNIT |
VSNR0IN2-BU3100 |
| |
|
| Marketing Name |
ROG Strix SCAR 18 |
| Color |
Off Black |
| Dimension (W x D x H) |
39.9 x 29.4 x 2.31 ~ 3.08 cm (15.71" x 11.57" x 0.91" ~ 1.21") |
| Weight |
3.10 Kg ( lbs) |
| Processor |
Intel Raptor Lake i9-14***HX-T6K(8P+16e) |
| Chipset |
Mobile Intel® HM770 Express Chipsets |
| Discrete/Optimus |
MUX Switch + NVIDIA® Advanced Optimus |
| Graphic |
NVIDIA® GeForce RTX™ 4080 Laptop GPU |
| Graphic Wattage |
ROG Boost: 2330MHz* at 175W (2280MHz Boost Clock+50MHz OC, 150W+25W Dynamic Boost) |
| Graphic Memory |
12GB GDDR6 |
| IGPU |
Intel® UHD Graphics |
| Panel Size |
18-inch |
| Resolution |
QHD+ 16:10 (2560 x 1600, WQXGA) |
| Refresh Rate |
240Hz |
| Response Time (G2G) |
3ms |
| Viewing Angle |
85/85/85/85 |
| Panel Tech |
Mini LED |
| Brightness |
1100nits |
| Contrast |
100000:1 |
| DCI-P3 % |
100.00% |
| Anti glare |
Anti-glare display |
| Adaptive-Sync technology |
G-Sync |
| Pantone |
Pantone Validated |
| Nebula Display |
ROG Nebula HDR Display |
| Support Dolby Vision HDR |
Yes |
| On board memory |
N/A |
| DIMM Memory |
16GB DDR5-5600 SO-DIMM, the memory speed of the systems vary by CPU SPEC |
| Total System Memory |
DDR5 16GB |
| Memory Slot |
2x SO-DIMM slots |
| Memory Max. |
64GB |
| Multi-channel memory technology |
Support dual channel memory |
| System Storage Installed |
1TB PCIe® 4.0 NVMe™ M.2 Performance SSD |
| M.2 slots support either SATA or NVMe |
2 |
| M.2 SSD Support List |
512GB/1TB/2TB G4x4 PCIe SSD |
| Expansion Slot (includes used) |
2x DDR5 SO-DIMM slots
2x PCIe |
| LAN |
10/100/1000/2500 Mbps |
| On board Wireless |
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.2 Wireless Card (*Bluetooth® version may change with OS version different.) |
| Wi-Fi/Bluetooth |
Wi-Fi 6E(802.11ax) (Triple band) 2*2 + Bluetooth® 5.3 Wireless Card (*Bluetooth® version may change with OS version different.) |
| I/O Ports |
1x 2.5G LAN port
1x Thunderbolt™ 4 support DisplayPort™ / G-SYNC
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery / G-SYNC
2x USB 3.2 Gen 2 Type-A |
| Display output |
1x HDMI 2.1 FRL |
| Audio |
1x 3.5mm Combo Audio Jack |
| Webcam |
720P HD camera |
| Mic |
Built-in array microphone |
| Keyboard Type |
Backlit Chiclet Keyboard Per-Key RGB |
| NumberPad |
N/A |
| Aura Sync |
Yes |
| Speakers |
4-speaker system with Smart Amplifier Technology |
| Audio Tech |
AI noise-canceling technology
Dolby Atmos
Hi-Res certification
Smart Amp Technology |
| Operating System |
Windows 11 Home |
|
