| Part No |
90NR0911-M001D0 |
| Model Name |
GU603ZM-K8042 |
| |
|
| EAN Code |
4711081629559 |
| UPC Code |
195553629553 |
| |
|
| Marketing Name |
ROG Zephyrus M16 |
| Color |
Off Black |
| Dimension (W x D x H) |
35.5 x 24.3 x 1.99 ~ 1.99 cm |
| Weight |
2.00 Kg |
| Processor |
12th Gen Intel® Core™ i7-12700H Processor 2.3 GHz (24M Cache, up to 4.7 GHz, 14 cores: 6 P-cores and 8 E-cores) |
| Chipset |
TBD |
| Discrete/Optimus |
MUX Switch + Optimus |
| Graphic |
NVIDIA® GeForce RTX™ 3060 Laptop GPU |
| Graphic Wattage |
ROG Boost: 1475MHz* at 120W (1425MHz Boost Clock+50MHz OC, 100W+20W Dynamic Boost) |
| Graphic Memory |
6GB GDDR6 |
| IGPU |
Intel® UHD Graphics 630 |
| Panel Size |
16-inch |
| Resolution |
QHD+ 16:10 (2560 x 1600, WQXGA) |
| Refresh Rate |
165Hz |
| Response Time (G2G) |
3ms |
| Viewing Angle |
85/85/85/85 |
| Panel Tech |
IPS-level |
| Brightness |
500nits |
| Contrast |
1200:1 |
| DCI-P3 % |
100% |
| Anti glare |
anti-glare display |
| Adaptive-Sync technology |
Adaptive-Sync |
| Pantone |
Pantone Validated |
| Nebula Display |
ROG Nebula Display |
| Total System Memory |
8GB DDR5 on board + 8GB DDR5-4800 SO-DIMM |
| On board memory |
8GB DDR5 on board |
| Memory Slot |
1x SO-DIMM slot |
| DIMM Memory |
8GB DDR5-4800 SO-DIMM |
| Memory Max. |
40GB |
| Multi-channel memory technology |
Support dual channel memory |
| System Storage Installed |
512GB PCIe® 4.0 NVMe™ M.2 Performance SSD |
| M.2 slots support either SATA or NVMe |
2 |
| M.2 SSD Support List |
Performance PCIe G4x4
SSD M2 2280 P4X4 512G
SSD M2 2280 P4X4 1TB
SSD M2 2280 P4X4 2TB |
| How to upgrade memory |
Upgradable |
| Expansion Slot (includes used) |
1x DDR5 SO-DIMM slot
1x PCIe |
| LAN |
10/100/1000/2500 Mbps |
| Wi-Fi/Bluetooth |
Wi-Fi 6E(802.11ax) (Dual band) 2*2 + Bluetooth 5.2 (*BT version may change with OS upgrades.) |
| I/O Ports |
1x RJ45 LAN port
1x Thunderbolt™ 4 support DisplayPort™ / power delivery
1x USB 3.2 Gen 2 Type-C support DisplayPort™ / power delivery
2x USB 3.2 Gen 2 Type-A
1x card reader (microSD) (UHS-II, 312MB/s) |
| Display output |
1x HDMI 2.0b |
| Audio |
1x 3.5mm Combo Audio Jack |
| Webcam |
720P HD IR Camera for Windows Hello |
| Mic |
Built-in array microphone |
| Keyboard Type |
Backlit Chiclet Keyboard RGB |
| NumberPad |
N/A |
| Aura Sync |
N/A |
| Speakers |
2x 2W dual-force woofer with Smart Amp Technology
2x 2W tweeter |
| Audio Tech |
AI noise-canceling technology
Dolby Atmos
Hi-Res certification
Smart Amp Technology |
| Operating System |
No preinstalled OS |
| Antivirus |
N/A |
| Security |
BIOS Administrator Password and User Password Protection
Kensington Security Slot™ |
| Battery |
90WHrs, 4S1P, 4-cell Li-ion |
| Power |
o6.0, 240W AC Adapter, Output: 20V DC, 12A, 240W, Input: 100~240C AC 50/60Hz universal |
| Reparability Index (for FR) |
7.2 |
