Feature
Product Description
Premium Thunderbolt™ 4 Docking Experience: ThinkPad Thunderbolt 4 Workstation Dock delivers reliable and consistent industry leading video, data and power connectivity; Maximize Your Productivity: Expand your horizon with versatile 8K display support or multiple 4K displays support, Upto 230W Power Delivery to Workstation, silent firmware upgrades, VPro/AMT support and transfer data at lightning fast 40Gbps.; The ThinkPad Thunderbolt 4 Workstation Dock is future-proof and fully loaded to take your productivity, efficiency and creativity to the peak.
Top Features
- The ThinkPad Thunderbolt™ 4 Workstation Dock supports upto 230W PD
- Single 8K@30Hz or upto 4 4K@60HZ display support
- silent firmware upgrades, vPro/AMT Pass through support, and
- data transfer rates upto 40 Gbps
- (depending on host system and peripheral processing capability, file attributes, and other configuration and operating environment factors)
More Information
Technical Support
Dock Driver
Display Resolution
Tech Specs
| USB Ports | 4* USB-A 3.2 Gen 2 (1 always on)
1* USB-C 3.2 Gen 2 |
| Shipment Group | ThinkPad Universal TBT 4 Dock
300W AC Power adapter
Power cord
Setup poster&Warranty Poster 0.7m Thunderbolt 4 Split Cable |
| Included Accessory | 300W adapter, 1x power cord, 0.7m Thunderbolt 4 Split Cable |
| Supported OS | Win10 64 bit, Win11 64 bit |
| Minimum Relative Humidity (%) | 5% |
| Maximum Relative Humidity (%) | 95% |
| JAN | 4580551376114 |
| EAN | 0195348677295 |
| UPC | 195348677295 |
| Warranty Type | CRU |
| Warranty Period | 3 years |
| Maximum Operating Temperature | 40 celsius |
| Minimum Operating Temperature | 0 celsius |
| Packed Weight | 1.9Kg |
| Packed Dimensions (L x D x H) | 270*195*85mm |
| Package Type | brown box |
| Product Weight | 0.45Kg |
| Height | 30mm |
| Depth | 80mm |
| Length | 220mm |
| Driver Needed | Yes |
| Hardware Requirements | Host with USB-C/Thunderbolt port |
| Agency Approvals | CE-EMC, TUV Mark,KCC,Serbia Kvalitet, CU EAC |
| Color | Black/Red |
| Power Plug | Slim Tip |
| Power Button | Yes |
| Output Power | Max 230W |
| Power Delivery | Yes |
| Input Power | 20V 15A |
| Charging Port | DC-IN |
| Maximum Resolution/Refresh Rate | 1* 8K 30Hz Via HDMI 2.1 4*4K 60 Hz |
| Max Number of External Monitors | 4 |
| Physical Security Feature | 1* NanoSaver lock slot 1*MicroSaver lock slot |
| Ethernet | 1* Gigabit Ethernet |
| Audio Ports | 1* 3.5mm Audio combo Jack |
| Video Ports | 1* HDMI 2.1 2* DP 1.4 |
| Thunderbolt Port | 1* Thunderbolt Port - for Host connect 1* Thunderbolt Port - for Device connect |
| Brand | ThinkPad |
